•Oil gun of new type is equipped and the muzzle is equipped with non-dripping device.
•Suitable for all sorts of machinery, vehicles, airplanes, ships...etc.
•There are two independent and separate cycle systems of pump out there, which prevents air-compressor-exhaust moisture from getting to the oil inside the barrel and deteriorating its quality.
•The efficient instrument for infusing oil powerfully for lubrication and maintenance purpose.
•Special regulator device makes oil come out more smoothly.
•Pump of separate type: utilize the principle of liquid getting pumped and driven by air compressor to draw in liquid.
•The barrel body is made of high-grade steel plate.
•It came to become even durable and robust after being made manually.
•Oil usage:---
 Pressure Ratio (5:1): suitable to pump 0#~120# engine oil or general non-corrosive solvent.
 Flow Meter (Optional): 120-7471, 120-7472, 120-7473.
 Pressure Ratio (16:1): suitable to pump 140#~200# gear oil or general non-corrosive solvent.
•Capacity: 30L.
•Air Input Pressure: 4~9 bar / 60~130 psi.
•Pressure Ratio: 16:1.
•Grease Output Pressure: 64~144 bar / 960~2080 psi.
•Deliver Rate: 8 L/min.
•Hose Length: 10 FT.
•N.W: 20.5 kgs.
•G.W.: 23.5 kgs.
•Cuft: 6.2’
