Air Tools & Equipment

602-3031 / 602-3032 / 602-3033

Mini Type Lubricator
← →
Qty :
Add to Inquiry List
•602-3031: Port Size: 1/8” (PT, NPT).
•602-3032: Port Size: 1/4” (PT, NPT).
•602-3033: Port Size: 1/4” (PT, NPT).

•Compact design: Suitable for limited space application.
•Miniature type: Easy for installation.
•Drain release automatically when water accumulation is less than 1kg.
•Filter Element: 5u .
•Operating Temperature range: 5ºC ~ 60ºC.
•Drain Capacity: 15ml.
•Oil Capacity: 30ml.
•Recommendable Lubricants: ISO VG-32.

•602-3031: Port Size: 1/8” (PT, NPT).
•602-3032: Port Size: 1/4” (PT, NPT).
•602-3033: Port Size: 1/4” (PT, NPT).

•Compact design: Suitable for limited space application.
•Miniature type: Easy for installation.
•Drain release automatically when water accumulation is less than 1kg.
•Filter Element: 5u .
•Operating Temperature range: 5ºC ~ 60ºC.
•Drain Capacity: 15ml.
•Oil Capacity: 30ml.
•Recommendable Lubricants: ISO VG-32.
