•Display: 5 digits, 10mm (0.4”) LCD with function annunciation. Measurement & Range: 10 top 99,999 RPM.

•Resolution: 0.1 RPM (< 1,000 RPM). 1 RPM (1,000 RPM). Accuracy: 0.05% + 1 digit.

•Detecting distance: 50 - 2,000mm typically. (Detecting distance are that under the size of reflecting tape is 10mm square and the measuring RPM value is 1,800 RPM. The max. detecting distance may change under different environment, different reflecting tape or the measuring RPM beyond 1,800 RPM.).

•Battery: 4 x 1.5V AA (UM-3) battery.

•Memory: Last/Max./Min.value.

•Power Consumption: Approx. DC 20 mA.

•Laser Light Source: Less than 1mW. Class 2 laser red diode. Wave length is 645mm approximately.

•Time base: Quartz crystal, 4.194 MHz. Circuit: Exclusive one-chip of microcomputer LSI circuit.



•Laser light detecting source, long measuring range up to 2 meters, it is useful in the RPM measurement application where the machine would be a risk to the operator or close access is difficult or not possible.

•Wide measuring range from 10 to 100,000 RPM, 0.1 RPM resolution for the measured value < 1000 RPM.

•Microprocessor based circuit, crystal time base, high precision with 0.05% accuracy.

•High visible LCD display gives RPM reading exactly with no guessing or errors and saves battery energy.

•Memory with recall function, the last, max. min. value will be stored into the memory automatically.

•Size: 190 x 72 x 37mm (7.5 x 2.8 x 1.5 inch).

•Weight: 250g (0.55 LB) including battery.

•Display: 5 digits, 10mm (0.4”) LCD with function annunciation. Measurement & Range: 10 top 99,999 RPM.

•Resolution: 0.1 RPM (< 1,000 RPM). 1 RPM (1,000 RPM). Accuracy: 0.05% + 1 digit.

•Detecting distance: 50 - 2,000mm typically. (Detecting distance are that under the size of reflecting tape is 10mm square and the measuring RPM value is 1,800 RPM. The max. detecting distance may change under different environment, different reflecting tape or the measuring RPM beyond 1,800 RPM.).

•Battery: 4 x 1.5V AA (UM-3) battery.

•Memory: Last/Max./Min.value.

•Power Consumption: Approx. DC 20 mA.

•Laser Light Source: Less than 1mW. Class 2 laser red diode. Wave length is 645mm approximately.

•Time base: Quartz crystal, 4.194 MHz. Circuit: Exclusive one-chip of microcomputer LSI circuit.



•Laser light detecting source, long measuring range up to 2 meters, it is useful in the RPM measurement application where the machine would be a risk to the operator or close access is difficult or not possible.

•Wide measuring range from 10 to 100,000 RPM, 0.1 RPM resolution for the measured value < 1000 RPM.

•Microprocessor based circuit, crystal time base, high precision with 0.05% accuracy.

•High visible LCD display gives RPM reading exactly with no guessing or errors and saves battery energy.

•Memory with recall function, the last, max. min. value will be stored into the memory automatically.

•Size: 190 x 72 x 37mm (7.5 x 2.8 x 1.5 inch).

•Weight: 250g (0.55 LB) including battery.
