•Capacity: 200L.

•Air Input Pressure: 4 ~ 9 bar / 60 ~ 130 psi.

•Pressure Ratio: 45 : 1.

•Grease Output Pressure: 180 ~ 405 bar / 2700 ~ 5850 psi.

•Deliver Rate: 9g / cycle.

•Hose Length: 20 ft.

•N.W.: 173.0 kgs. G.W.: 215.0 kgs. CUFT: 20.5'.



•The Ouside Dimension:---

•Length: 740 mm.

•Width: 1050 mm.

•Mini Height: 1440 mm.

•Max Height: 2440 mm.



•Feature:---

  (1) Dual pneumatic cylinder structure design brings higher stability during operation, more average actuation force and smoother fluid output.

  (2) Special design of follower plate which enables the follower plate and container can be combined tighter. This can be used on high viscosity fluid and can further reduce the residual materials inside the container or at the bottom of container significantly.

  (3) The pneumatic cylinder auxiliary press is suitable for high viscosity grease or the grease that hard to extract by normal pump.

  (4) Suitable for original 50 gallon grease drum from every country.

  (5) The pump is made of aluminum alloy by forging.



•Grease usage: Available for normal 00#~3# grease.



•Operation:---

  Reciprocating pump with large flow enables smoother oil supply.

  The special design is for the container with taper. (drum inner dimension Ø265 ~φØ300).

  Synchronous pressurization of dual pneumatic cylinder which enables smoother extraction of high viscosity fluid.
